Pharmaceutical Heating Water Circulation Cooling Prevents Scaling Water Softening

• The single-tank, single-valve water softening system is manufactured at our factory in Tai'an, Shandong Province, China, with independent R&D, assembly and testing capabilities, and in accordance with the ISO9001 quality management system. All systems are subjected to rigorous pressure testing, water quality testing and operation simulation to ensure stable and reliable performance.

• The system uses ion exchange technology to remove calcium and magnesium ions from the water, effectively reducing water hardness and preventing system scaling and corrosion.

Company Profile

We are a high-tech enterprise specializing in the research, development, production and sales of water treatment equipment, with more than 10 years of experience in the design and manufacture of water treatment systems. Our products cover a wide range of water treatment equipment such as softened water, RO reverse osmosis, etc., which are widely used in food, pharmaceutical, chemical and other industries. Through continuous innovation and optimization, we provide customers with efficient, environmentally friendly and energy-saving water treatment solutions to help companies improve production efficiency and ensure product quality.

Core Advantages of Single Tank and Single Valve Water Softening System

• Effectively removes water hardness and ensures a stable production environment
• Fully automated operation, saving labor costs
• It saves energy and reduces long-term operating costs. The Single Tank Single Valve Water Softening System avoids waste by precisely controlling the amount of water and salt used.
• Compact design saves space

Specifications and Structure

• Treatment capacity: usually ranging from 1 ton/hour to 100 tons/hour, capable of meeting the needs of pharmaceutical plants of different sizes.
• Tank material: common materials for glass fiber reinforced plastic, stainless steel or rubber lined carbon steel, with corrosion resistance and high pressure resistance, to ensure long-term stable operation of the system.
• Resin capacity: the resin filling capacity is usually between 25L and 500L, the specific capacity is selected according to the size of the treated water.
• Control valve caliber: commonly used caliber for 1 “to 2”, caliber selection based on the flow requirements for optimization.
• The main components of the equipment include:
• Softening tank
  The softening tank is filled with ion exchange resins to remove the hardness components (calcium and magnesium ions) from the water, ensuring that the water quality meets the requirements of pharmaceutical production.
• Automatic control valve
  The automatic control valve is the core component of the system and is responsible for controlling the inflow, outflow and regeneration process of the water. Its automated function greatly reduces the complexity of manual management and improves the stability of system operation.
• Salt tank
  The salt tank is used for storing and supplying regeneration salt. The system regularly uses brine to regenerate the resin, ensuring a continuous and stable supply of softened water.
• Piping System
  The system is equipped with advanced piping connections to ensure smooth and leak-free water flow. Pipes are usually threaded or flanged to ensure a tight seal with the system.

Value in the Pharmaceutical Industry

• Equipment protection and longevity
  Minerals in hard water can cause scaling in pharmaceutical equipment and piping, affecting heat exchange and water flow and increasing the risk of failure.
• Improve cleaning effectiveness and reduce the risk of non-compliance.
